Bidirectional charging: Which cars are suitable for electricity storage?

The sun is shining, the solar roof is running at full speed, but where to put the excess electricity? The best way is to get into an e-car. The electricity stored there can be easily fed back into the home power grid if necessary and makes lamps light up and TVs running. How does that work? The magic word is bidirectional charging.

What is bidirectional charging?

Bidirectional charging means that energy is exchanged in both directions. The electric car can not only be charged with electricity, but also emit electricity. In the meantime, the e-car acts as an energy storage device, so to speak.

The first thing you have to know is that an electric car only runs on direct current, because the battery is only designed for this. Therefore, the alternating current from the power grid must be converted into direct current. If the car is stationary for a while and the power is not consumed, the battery simply stores the electricity.

If you now want to use the electricity from the e-car battery for house lighting, for example, the direct current must be converted back into alternating current. This is exactly what this charging process is all about, because it is no problem for appropriately designed chargers to achieve this.

Is bidirectional charging allowed in Germany?

Yes, bidirectional charging is allowed in Germany. The corresponding EU directive was already transposed into national law in 2019.

What are the areas of application for bidirectional charging?

There are three ways to use the energy stored in the e-car for other purposes:

Vehicle-to-home (V2H)

Those who decide to do this want to use the stored electricity to supply the home power grid. A converter that produces alternating current from direct current is usually integrated into the wallbox. Your electric car charges the in-house photovoltaic system, and the e-car was ideally fed by the solar system beforehand. Thus, the entire cycle is free of charge and sustainable for you.

Vehicle-to-grid (V2G)

This method is used to think bigger. This means integrating as many electric cars as possible into the energy grid. The energy stored in the electric car is to be fed back into the general power grid. This makes sense, for example, to counteract power peaks. If you charge the e-car during off-peak hours, you can return the energy at peak times to relieve the power grid.

Of course, you can also drive in the meantime, but most vehicles are parked a good 90 percent of the time, so it makes sense to use the V2G option. The e-car is thus used as an electricity storage device.

Vehicle-to-load (V2L)

As a third option, vehicle-to-load is a type of bidirectional charging. Here, the e-car provides power for other devices – e.g. laptop, smartphone or e-bike. There is a socket in the car where you can plug in the devices and charge them.

Which e-cars can charge bidirectionally?

The pioneer for this charging technology is Nissan, because the Nissan Leaf has been able to charge bidirectionally as an electric car for several years. In general, it can be said that models from Asian manufacturers are more often suitable for this, because the CHAdeMO connector, which is widely used in the Asian region, was designed for this from the beginning. Only for this connection is there currently a valid protocol for V2G charging in order to feed electricity into the public grid.

The CCS standard, which is widespread in Europe, usually does not yet master this.

The following models can currently (as of 09/2024) charge bidirectionally:

• Alpine A290
• Cupra Born
• Honda e
• Hyundai Ioniq 5
• Hyundai Ioniq 6
• Kia EV6
• Kia EV9
• Kia Niro EV
• MG4
• MG5
• Nissan Leaf
• Nissan e-NV200
• Mitsubishi Outlander Plug-in Hybrid
• Polestar 3
• Renault 5 E-Tech
• Skoda Enyaq iV
• Volvo EX90
• VW ID.3
• VW ID.4
• VW ID.5
• VW ID.7
• VW ID.7 Tourer
• VW ID. Buzz

The Ioniq 5 and its sister model EV6 confirm the exception to the CCS standard. The two models can also charge bidirectionally with this charging standard. However, Hyundai and Kia are not yet focusing on this charging technology in their development. However, it would be possible to charge external devices with up to 3.7 kW via an adapter on the CCS connection. Accordingly, one could also give other e-cars a jump start.

Does a Tesla support bidirectional charging?

No, currently no Tesla model supports bidirectional charging.

Are there plans for bidirectional charging at VW?

Since the end of 2023, some ID. models have supported bidirectional charging. If you have a new ID. model with a 77 kWh battery, then the vehicle is equipped with bidirectional charging. For vehicles already delivered, the function is also to be made possible by means of an update to the ID. Software 3.5.

What technical requirements do you need?

It is important that all parameters involved communicate with each other, i.e. that they can understand each other and work together. The following three conditions must be met:

• An electric car
• A suitable charging infrastructure or wallbox
• A uniform language – i.e. software

An electric car is best suited for the purpose of bidirectional charging, plug-in hybrid models can do that too, but are rather negligible for the future. They only have a small battery that can store only a small amount of electricity.

In order for this technology to be implemented on a large scale, a suitable charging infrastructure is needed. This refers to both public charging stations and wallboxes for home use. These devices must convert alternating current into direct current, produce the correct voltage and have a suitable communication standard.

That brings us to the language. As already mentioned, only the CHAdeMO standard is currently designed for bidirectional charging. CCS is catching up, but still has a lot of catching up to do.

Bidirectional wallbox: What models are there?

In the meantime, there are already some wallboxes that support bidirectional charging. Here is a selection of providers and corresponding wallboxes:

• openWB Pro
• Smartfox Pro Charger 2
• E3/DC Edison BiDi Wallbox
• Evtec sospeso&charge
• Sigenergy Sigen EV DC Charging Module
• VW bidirectional ID. Charger
• Ford Charge Station Pro
• Sono Wallbox

By the way: If you would like to fill up with cheap car electricity, then take a look at the tariffs of our car electricity partners.

Energy transition and the environment: What can bidirectional charging contribute?

Producing electricity only sustainably is a major challenge. Especially when it comes to the changing weather, because solar and wind energy are not yet sufficiently available, especially in winter. A large number of electric cars that are integrated into the power grid and serve as buffer storage could have a real effect here.

If the batteries of the e-cars are charged when there is enough sun or wind available and this energy is then fed back into the power grid in bad weather or when there is no wind, the share of renewable energies in our power grid would be increased.

Bidirectional charging in Germany from 2025

Federal Minister of Economics Habeck has invited to the second summit for bidirectional charging. At the end of October 2024, around 90 decision-makers from Europe met there to discuss the next steps towards the introduction of bidirectional charging in Germany from 2025.

It is expected that this will stabilize the electricity system and increase flexibility. In addition, e-car owners should of course benefit and earn money if they make their car available as an electricity storage device. There are still some hurdles to overcome, especially legal ones.

There will be a final meeting in May 2025, then we will see whether an introduction in 2025 is realistic.
